10K OHM Linear Taper Potentiometer On-Off Switch PCB Mount Knurled Shaft Dia: 6mm
$1.39

10K OHM Linear Taper Potentiometer On-Off Switch PCB Mount Knurled Shaft Dia: 6mm

Available Qty: 14
SKU: A-5737
ALPHA
ALPHA 24MM
DUST SEAL
SHAFT DIA: 6MM
On-Off Switch
B10K OHM LINEAR
PCB Mount
$1.39
Have questions? Expert help just one click away Contact Us

Product Description

Manufacturer: ALPHA
Manufacturer Part No: RV24AS-40-15K-B10K
Datasheet: Click Here
With Dust Seal

Specifications
Power: 0.5W
Resistance: 10K OHM OHMS
Maximum Working Voltage: 500VAC
Switch Rating Voltage: 12VDC , 1A
Type: Linear
Type B
Features
On-Off Switch
PC Mount
Knurled Shaft
Suits Most Standard knobs
Shaft Diameter: 6mm
Shaft Length: 6mm
Length of thread : 6.5mm
Total Shaft Length(L):15 mm
Mounting Hole: 8mm
Base Diameter: 24mm
Lead Thickness: 2mm
Total Rotation Angle: 300 ± 5°

More Information

Same Spec Items -
SKU A-5737
Manufacturer ALPHA
MPN RV24AS-40-15K-B10K
Can be used with -

Customer Ratings

There are no reviews yet
