Full Wave Dual DC Power Circuit up to 3 Amps / 50V K020

SKU: A-5213-1

$5.99

Have questions? Expert help just one click away Contact Us

Customize Full Wave Dual DC Power Circuit up to 3 Amps / 50V K020

1 x Full Wave Dual DC Power Circuit up to 3 Amps / 50V K020   + $5.99
1 x KIT K020 Schematics PDF (Out of Stock)   + $0.00

Your Customization

Full Wave Dual DC Power Circuit up to 3 Amps / 50V K020

Summary
Final product price

Product Description

Full Wave Dual DC Power Circuit up to 3 Amps / 50V K020

All parts required to assemble this kit will be shipped to you.
No transformer is provided.
Preformatted board included. ( not an Etched printed circuit board)
Datasheet & Guide will be sent to you via email in PDF file format after your order confirmation.

Description
K020: This kit provides parts to build a circuit that converts A/C to D/C, with power handling up to 50 volts and 3 amps Max with positive, Negative, and neutral rails. Filter capacitors included.

Learn the real assembly as it is up to you to layout your parts on the preformatted board.
Schematics and parts are included to complete this project, along with a quick reference guide for parts polarity and the likes.
Experiment with layouts, try different ones that may be a better method.
Keep parts lengths short, and watch for shorts.
Read the guide included for tips.

More Information

Same Spec Items -
SKU A-5213-1
MPN K020
Can be used with -
