Dual 05 Volt (+, Net, -) 1 Amp Regulator Kit with Filter Capacitors K023

SKU: A-5210-1

$5.59

Have questions? Expert help just one click away Contact Us

Customize Dual 05 Volt (+, Net, -) 1 Amp Regulator Kit with Filter Capacitors K023

1 x Dual 05 Volt (+, Net, -) 1 Amp Regulator Kit with Filter Capacitors K023   + $5.59
1 x KIT K023 Schematics PDF (Out of Stock)   + $0.00

Your Customization

Dual 05 Volt (+, Net, -) 1 Amp Regulator Kit with Filter Capacitors K023

Summary
Final product price

Product Description

 Dual 05 Volt (+, Net, -) 1 Amp Regulator Kit with Filter Capacitors K023

All parts required to assemble this kit will be shipped to you.
No transformer is provided.
Preformatted board included. ( not an Etched printed circuit board)
Datasheet & Guide will be sent to you via email in PDF file format after your order confirmation.

Description
Regulate your existing DC power or one of our AC to DC converter Kits (K010, K020) with this kit, Provide fixed voltage rating and 1 amp output with thermal shutdown and short circuit protection. Power your kits or other DC electronic devices you have.

Learn the real assembly as it is up to you to layout your parts on the preformatted board.
Schematics and parts are included to complete this project, along with a quick reference guide for parts polarity and the likes.
Experiment with layouts, try different ones that may be a better method.
Keep parts lengths short, and watch for shorts.
Read the guide included for tips.

More Information

Same Spec Items -
SKU A-5210-1
MPN K023
