Mini Relay DPDT RY-9W-K 9VDC 8PIN 2Poles 1A

Manufacturer : FUJITSU COMPONENTS
Manufacturer Part No. : RY-9W-K
Datasheet : Click Here
RoHS : YES

Specification
Coil Voltage : 9VDC
Contact Rating : 1A
Switch Function : DPDT(2 Form C)
Contact Rating : 0.5A/120VAC , 1A/24VDC
Type : High Sensitive
Operating Function : Non-Latching Type
Mounting : PCBThough Hole
Dimension(WxDxH) : 9.8 x 20.2 x 12.5 mm

Features
For signal switching,Bifurcated Style,Ultra high sensitivity,Surge stength 1500 V,Wide operating range,High reliability-bifurcated contacts
