CD4012BE CD4012 4012 DUAL 4-Input NAND GATE IC

Be the first to review this product

$0.25

Qty Available: 119017

In stock

Quick Overview

Texas Instruments - Get It Fast - Same Day Shipping

Details

Manufacturer: Texas Instruments
Manufacturer Part No: CD4012BE
Package / Case: PDIP-14
RoHS: Yes
Datasheet: Click Here

Specifications
Product Category: Gates (AND / NAND / OR / NOR)
Logic Family: CD4000
Logic Type: CMOS
Number of Circuits: Dual
High Level Output Current: - 4.2 mA (Min)
Low Level Output Current: 4.2 mA (Min)
Propagation Delay Time: 250 ns @ 5 V
Supply Voltage (Max): 18 V
Supply Voltage (Min): 3 V
Maximum Operating Temperature: 125 C
Minimum Operating Temperature: - 55 C
Function: NAND
Number of Lines (Input / Output): 4-IN / 1
Number of Output Lines: 1
Operating Supply Voltage: 3.3 V or 5 V or 9 V or 12 V or 15
MICROPOWER PHASE-LOCKED LOOP

Additional Information

Manufacturer Texas Instruments
MPN CD4012BE
SKU A-009
