• M74HC595B1R 74HC595 74595 8 bit Shift Register IC

M74HC595B1R 74HC595 74595 8 bit Shift Register IC

Be the first to review this product


Qty Available: 108806

In stock

Quick Overview

STMicroelectronics - SGS THOMSON/TEXAS INSTRUMENTS - Get It Fast - Same Day Shipping


Probably the most popular and easiest to use 8 bit shift register. It's often used to control a lot of LED's or for lots of switches from a micro controller. The 74HC595 has lots of examples and is widely used with Arduino's. With a single 74HC595, you can control 8 LED's with just three lines on the Arduino. But the best part is that you control a number of 74HC595's from the same three lines. So you can get 16, 24, 32, or more! LED's all controlled from a single Arduino.

Here is a pinout of the 74HC595.

Here is a Fritzing wiring example with an Arduino Uno

The Arduino website has some example code to get all eight LED's to light up correctly as well as further adding in more 74HC595's to control even more LED's. Click here

Manufacturer: STMicroelectronics SGS THOMSON/TAXAS INSTRUMENTS
Manufacturer Part No: M74HC595B1R
Package / Case: PDIP-16
RoHS: Yes
Datasheet: Click Here

Technology : CMOS
Number of Elements : Single
Number of Bits : 8
Logic Family : HC
Logical Function : Shift Register
Output Type : 3-State
Propagation Delay Time : 285ns
Operating Supply Voltage (Typ) : 2.5/3.3/5V
Operating Temp Range : -55C to 125C
Operating Supply Voltage (Min) : 2V
Operating Supply Voltage (Max) : 6V
Operating Temperature Classification : Military
Mounting : Through Hole
Pin Count : 16

Additional Information

Manufacturer STMicroelectronics - SGS THOMSON/TEXAS INSTRUMENTS
SKU A-024
