CD74HC4051 74HC4051 744051 IC 8-CHANNEL ANALOG MULTIPLEXER

SKU
A-026
$0.46
In stock Qty Available: 92

Quick Overview

VARIOUS - Get It Fast - Same Day Shipping

Details

This demultiplexer and multiplexer allows use in both directions. It is easy to use. Select 1 of 8 inputs or outputs for a single output or a single input respectively. This chip works with digital or analog logic.

If you want to use it as a multiplexer, you can select (output) a single input of 8 options.

If you want to use this is a demultiplexer you can write to a single output from 8 different options.

Pinout of the 74HC4051


There is some example code for working with an Arduino that is available by clicking here

Manufacturer:
VARIOUS
Manufacturer Part No: CD74HC4051EE4
Package / Case: PDIP-16
RoHS: Yes


Specifications
Decoder / Encoder / Multiplexer / Demultiplexer Logic IC
Logic Type:Analog Multiplexer/Demultiplexer
Logic Family:HC
Logic Base Number:744051
On Resistance, Rds(on):80ohm
No. of Outputs:8
No. of Pins:16

Additional Information

More Information
SKU A-026
Manufacturer VARIOUS
MPN CD74HC4051EE4
