Details
Manufacturer Part No: SN74HC244N
Package / Case: PDIP-20
RoHS: Yes
Datasheet: Click Here
Specifications
Product Category: Buffers & Line Drivers
Logic Type: CMOS
Logic Family: HC
Number of Channels per Chip: Octal
Polarity: Non-Inverting
Output Type: 3-State
High Level Output Current: - 7.8 mA
Low Level Output Current: 7.8 mA
Propagation Delay Time: 165 ns @ 2 V or 33 ns @ 4.5 V or 28 ns @ 6 V
Supply Voltage (Max): 6 V
Supply Voltage (Min): 2 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Packaging: Tube
Function: Buffer/Line Driver
Input Signal Type: Single-Ended
Number of Circuits: Dual
Number of Lines (Input / Output): 8 / 8
Number of Output Lines: 8
Operating Supply Voltage: 5 V
Additional Information
| Manufacturer | Texas Instruments |
|---|---|
| MPN | SN74HC244N |
| SKU | A-208 |
